Motor supports both sensored and sensorless operation For connection to VESC: 6‑pin adapter cable required (2.0 mm female to 1.5 mm male ESC sensor wire) Sensor Wire Configuration: Red=5V, White=Temp, Blue=A, Yellow=C, Green=B, Black=GND
| Max Current | 75 A |
| Input Voltage | 4–12S |
| Max Torque | 5 Nm |
| Internal Resistance | 0.05 Ohm |
| Recommended ESC | 3–12S 50A |
| Motor Net Weight | 860 g (1.9 lb) |
| Motor Diameter | 63 mm |
| Motor Length | 74 mm (Φ2.5×2.9 inch) |
| Shaft | Diameter 8 mm (0.31 inch), length 30 mm, 3×1.5 mm keyway |
| Motor Wires | Default 12AWG silicone wire with 4.0 mm banana connector (male); 5.5 mm gold-plated connector available upon request |
| Wire Configuration | Blue=A, Black=B, Yellow=C |
| Stator | 0.2 mm imported Japanese silicon steel sheet |
| Magnet | N42SH high-temperature grade magnet |
| Hall Sensor Wire | Standard RC sensor wire JST‑ZH 6‑pin 1.5 mm pitch / 2.0 mm 6‑pin; internal PCB with 120° Hall effect sensors |
Motor supports both sensored and sensorless operation For connection to VESC: 6‑pin adapter cable required (2.0 mm female to 1.5 mm male ESC sensor wire) Sensor Wire Configuration: Red=5V, White=Temp, Blue=A, Yellow=C, Green=B, Black=GND
