Internal PCB with 120° Hall effect sensors Motor supports both sensored and sensorless operation For connection to VESC: 6‑pin adapter cable required (2.0 mm female to 1.5 mm male ESC sensor wire) Sensor Wire Configuration: Red=5V, White=Temp, Blue=A, Yellow=C, Green=B, Black=GND Suitable for 63 mm motor mounts
| Max Output Power | 4000 Watts |
| Max Current | 95 A |
| Input Voltage | 4–13S |
| Max Torque | 7 Nm |
| Internal Resistance | 0.05 Ohm |
| Recommended ESC | 3–13S 100A |
| Motor Net Weight | 1000 g |
| Motor Diameter | 63 mm |
| Motor Length | 84 mm |
| Shaft | Diameter 10 mm with keyway |
| Motor Wires | Default 12AWG silicone wire with 4.0 mm banana connector (male); 5.5 mm gold-plated connector available upon request |
| Wire Configuration: | Blue=A, Black=B, Yellow=C |
| Stator: | 0.2 mm imported Japanese silicon steel sheet |
| Magnet: | N42SH high-temperature grade magnet |
Internal PCB with 120° Hall effect sensors Motor supports both sensored and sensorless operation For connection to VESC: 6‑pin adapter cable required (2.0 mm female to 1.5 mm male ESC sensor wire) Sensor Wire Configuration: Red=5V, White=Temp, Blue=A, Yellow=C, Green=B, Black=GND Suitable for 63 mm motor mounts
